Simplex RLS502 RLS Low Profile Single Acting Spring Return Hydraulic Cylinder, 50 ton, 3-1/2 in Dia Bore, 2.38 in L Stroke, 4.81 in H Retract, 2-3/4 in Dia Rod, 10000 psi

PART TKSRLS502
WEIGHT 24.00000
SUPPLIER Simplex
SUPPLIER PART # RLS502
Calculating price...
QUANTITY

About this item

Simplex Hydraulic Cylinder, Low Profile Single Acting Spring Return, Series: RLS, 50 ton Capacity, 3-1/2 in Dia Bore, 2.38 in Stroke Length, 4.81 in H Retract, 2-3/4 in Rod Diameter, 10000 psi Pressure, Steel Housing Material, 4.87 in OD Dimensions

ANSI Specified|ASME B30.1
Catalog
Catalog
Warranty Information
Warranty Information
Bore Size 3-1/2 in Dia
Capacity 50 ton
Dimensions 4.87 in OD
Housing Material Steel
Pressure Rating 10000 psi
Retract 4.81 in H
Rod Diameter 2-3/4 in
Series RLS
Stroke Length 2.38 in
Type Low Profile Single Acting Spring Return
Brand Simplex®
Country of Origin US
Warranty Limited
