949167 2-Piece Ball Valve, 1-1/2 in Nominal, ASTM-A351 CF8M 316 Stainless Steel Body, Full Port, RPTFE Seal/Thrust Washer/Plastic Cover Softgoods, Import

PART MIM949167
WEIGHT 3.33000
SUPPLIER Preferred Supplier
SUPPLIER PART # 949167

About this item

Ball Valve, 2-Piece, 1-1/2 in Nominal, 1000 psi WOG, 125 psi WSP, -60 to 450 deg F, Full Port, Media: Cold Water, Oil, Gas and Saturated Steam, ASTM A351 CF8M 316 Stainless Steel Ball, ASTM-A351 CF8M 316 Stainless Steel Body, AISI 316 Stainless Steel Stem/Reinforced PTFE Seat Trim, RPTFE Seal/Thrust Washer/Plastic Cover, 3.29 in H x 4.65 in W, Import

ITEM FEATURES:

  • Quality manufactured for harsh environments
  • Investment casting body
  • Adjustable stem packing
  • Blow-out proof stem and safe pressure-reducing hole
  • Locking handle with blue generic sleeve
  • Corrosion-resistant
  • 100% leakage tested at 100 psi air under water
  • Generic handles
  • 1500 psi hydrostatic test pressure
  • ASTM-A351 CF8M 316 stainless steel body cap, AISI 304 stainless steel nut, gland nut, washer and handle
  • RPTFE seal, thrust washer and plastic cover
